00Cr15Ni60Mo16W4 TIG MIG Wire ERNiCrMo-4 C276 Nickel Base Alloy Welding Wire

Production Description

ERNiCrMo-4 (UNS N10276)

C-276 alloy Welding Wire is used for welding Hastelloy C276, nickel-based alloys and dissimilar materials, nickel alloys and steel or stainless steel, and also for cladding nickel-chromium-molybdenum alloy composite layers on steel. The alloy is resistant to corrosion by various acids and acid vapors. Due to its high molybdenum content, it has strong resistance to stress corrosion cracking, pitting and crevice corrosion. It is widely used in chemical container pipelines, pumps and valves, flue gas desulfurization in the power industry, and welding of 9% Ni steel for -196℃ applications.

Composition and characteristics

The main components of ERNiCrMo-4 welding wire include:

Nickel (Ni): Nickel is one of the main components of this welding wire, providing good corrosion resistance and high temperature performance.

Chromium (Cr): The addition of chromium can improve the corrosion resistance of welded parts, especially for high temperature corrosion resistance.

Molybdenum (Mo): The addition of molybdenum can increase the strength and corrosion resistance of welds.

Other alloying elements: such as titanium (Ti), iron (Fe), etc., are used to adjust the properties and structure of the alloy.

ERNiCrMo-4 welding wire has the following main characteristics:

Excellent corrosion resistance: It has excellent corrosion resistance in various corrosive media, especially suitable for acidic, alkaline and chloride environments.

High temperature performance: It has good high temperature strength and oxidation resistance, and can maintain stable welding performance at high temperatures.

Good mechanical properties: The welded joint has high strength and good plasticity, which can meet the requirements of complex engineering structures.

Easy to weld: It has good welding performance and can be welded by various common welding methods, such as argon arc welding, TIG welding, etc.

Application fields

ERNiCrMo-4 welding wire is widely used in the following fields:

Chemical industry: used for welding of corrosion-resistant equipment such as chemical equipment, reactors, and heat exchangers.

Aerospace field: used for welding of aircraft engines, spacecraft parts and other high-temperature and high-pressure environments.

Marine engineering: used for welding of marine engineering structures such as offshore platforms and offshore pipelines, with good seawater corrosion resistance.

Nuclear energy industry:used for welding of nuclear energy equipment such as nuclear reactors and nuclear power plants, and can withstand the test of radiation and high-temperature environments.

Preparation process

The preparation process of ERNiCrMo-4 welding wire usually includes the following steps:

Raw material preparation: Select high-quality metal raw materials to ensure that their chemical composition and physical properties meet the requirements.

Alloy smelting: Put the raw materials into the arc melting furnace for smelting, control the smelting temperature and atmosphere, and ensure that the alloy composition is uniform.

Wire drawing: The smelted alloy liquid is drawn into welding wire of the required diameter through a wire drawing machine.

Surface treatment: Clean and treat the surface of the welding wire to remove oxides and impurities and improve welding quality.

Optimization of the preparation process can improve the quality and performance of the welding wire, reduce production costs, and improve production efficiency.
