Hastelloy C276 AWS ERNiCrMo-4 Nickel-Chromium-Molybdenum Welding Wire

Product Details

ERNiCrMo-4 Welding Wire is a type of filler wire specifically designed for welding applications involving Hastelloy C276 alloy. Hastelloy C276 is a nickel-molybdenum-chromium alloy known for its excellent corrosion resistance in a wide range of aggressive environments, including acids, chlorides, and oxidizing media.

The welding wire is used in various welding processes, such as gas tungsten arc welding (GTAW or TIG) and gas metal arc welding (GMAW or MIG), to join or overlay Hastelloy C276 components or to create protective coatings on other materials.

Specifications: AWS A5.14  ERNiCrMo-4;ASME II  SFA-5.14  ERNiCrMo-4 ; UNS N10276 ; SNi6276 (NiCr15Mo16Fe6W4)

Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM

Form: MIG(15kgs/spool), TIG(5kgs/box)

Advantages:

• Corrosion Resistance: Hastelloy C276 exhibits outstanding resistance to corrosion, making it suitable for welding applications in aggressive environments, including chemical processing, petrochemical, and waste treatment industries.

• Versatility: Hastelloy C276 welding wire can be used for both joining similar alloys and overlaying other substrates to provide a corrosion-resistant coating. It is compatible with a wide range of base materials, including stainless steels, nickel alloys, and carbon steels.

• High-Temperature Strength: Hastelloy C276 maintains good mechanical strength and integrity at elevated temperatures, allowing welded joints to withstand high-temperature service conditions.

• Weldability: The welding wire offers excellent weldability and can produce high-quality welds with good mechanical properties. It provides good fusion and wetting characteristics, enabling the formation of sound welds with minimal defects.

• Chemical Composition: Hastelloy C276 welding wire typically contains approximately 15-17% molybdenum, 14-16% chromium, 4-7% iron, 3-5% tungsten, 2.5% cobalt, 1.5-3% manganese, and small amounts of other elements such as nickel, carbon, and silicon.

•


•


Application:

• Chemical and petrochemical processing,

• Oil and gas,

• Power generation

• Pharmaceutical, pulp, paper production

• Wastewater treatment


•


Specfication:

ERNiCrMo-3 is used primarily for gas tungsten and gas metal arc and matching composition base metals.It is also used for welding Inconel 601 and Incoloy 800. It can be used to weld dissimilar metal combinations such as steel, stainless steel, Inconel and Incoloy alloys.

ERNiCrMo-4 is used for welding nickel-chromium-molybdenum base materials to itself, steel and other nickel base alloys and for cladding steel.

ERNiCrMo-10 is used for welding nickel-chromium-molybdenum base materials to themselves, steel and other nickel base alloys, and for cladding steels. Can be used to weld duplex, super duplex stainless steels.

ERNiCrMo-14 is used for gas-tungsten-arc and gas-metal-arc welding of duplex, super-duplex and super-austenitic stainless steels, as well as nickel alloys such as UNS N06059 and N06022, INCONEL alloy C-276, and INCONEL alloys 22, 625, and 686.

ERNiCrFe-7 is used for gas-tungsten-arc and gas-metal-arc welding of INCONEL 690.

ENiCrFe-3 electrodes are used for welding of nickel-chromium-iron alloys to themselves and for dissimilar welding between nickel-chromium-iron alloys and steels or stainless steels.

ERCuNi is used for gas metal and gas tungsten arc welding. Can also be used by oxy-fuel welding of 70/30, 80/20, and 90/10 copper nickel alloys. A barrier layer of nickel alloy 610 is recommended prior to overlaying steel with GMAW weld process.

ERNiCu-7 is a copper-nickel alloy base wire for GMAW and GTAW welding of Monel alloys 400 and 404. Also used for overlaying steel after first applying Layer of 610 nickel

ERNi-1 is used for GMAW, GTAW and ASAW welding of Nickel 200 and 201, joining these alloys to stainless and carbon steels, and other nickel and copper-nickel base metals. Also used for overlaying steel.
