Nickel Welding Wire ERNiCrMo-3 Superior Corrosion Resistance for High-Temperature

Product Description：

Nickel based Inconel 625 Welding Wire ERNiCrMo-3 has good resistance to corrosion and high temperature,and has high strength and good fabricability.ERNiCrMo-3 is a high-performance nickel-chromium-molybdenum alloy welding wire designed for use in a variety of demanding applications. Known for its excellent resistance to corrosion and oxidation, it is primarily used for welding dissimilar materials, including stainless steels, and other corrosion-resistant alloys. This wire is widely used in industries requiring robust performance under extreme conditions, such as chemical processing, power generation, and marine environments.

Features:

• Excellent Corrosion Resistance: Offers superior resistance to general corrosion, pitting, and crevice corrosion, particularly in aggressive environments such as those containing chlorides.

• High Temperature Strength: Withstands high temperatures and offers excellent resistance to thermal fatigue and oxidation at elevated temperatures.

• Good Weldability: Easy to use with excellent arc stability and smooth bead formation, even in difficult-to-weld situations.

• Dissimilar Metal Welding: Ideal for welding a range of dissimilar materials, including austenitic stainless steels to nickel alloys and mild steel.

• Molybdenum Content: The addition of molybdenum enhances resistance to pitting and crevice corrosion, making it suitable for use in harsh chemical and marine environments.

Applications:

• Chemical Processing: Used in welding piping, tanks, and reactors for industries like petrochemicals, pharmaceuticals, and food processing.

• Power Generation: Ideal for welding heat exchangers, reactors, and other components subjected to high temperatures and corrosive environments.

• Marine and Offshore Applications: Particularly useful in welding parts exposed to seawater, ensuring longevity and resistance to corrosion.

• Pressure Vessel Fabrication: Suitable for welding pressure vessels and components in high-stress, high-temperature environments.

• Aerospace: Used in components exposed to extreme temperatures and corrosive conditions.

Standard Specifications:

• AWS A5.14 ERNiCrMo-3

• ASME SFA-5.14

Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM

Form: MIG(15kgs/spool), TIG(5kgs/box)

• High temperature tolerance

• Good corrosion resistance

• Smooth surface

• Less oxides

• Good fluidity of the molten pool

• High welding strength

• Different spool for choosing

• Meets GB and ASTM standards

Specfication:

ERNiCrMo-3 is used primarily for gas tungsten and gas metal arc and matching composition base metals.It is also used for welding Inconel 601 and Incoloy 800. It can be used to weld dissimilar metal combinations such as steel, stainless steel, Inconel and Incoloy alloys.

ERNiCrMo-4 is used for welding nickel-chromium-molybdenum base materials to itself, steel and other nickel base alloys and for cladding steel.

ERNiCrMo-10 is used for welding nickel-chromium-molybdenum base materials to themselves, steel and other nickel base alloys, and for cladding steels. Can be used to weld duplex, super duplex stainless steels.

ERNiCrMo-14 is used for gas-tungsten-arc and gas-metal-arc welding of duplex, super-duplex and super-austenitic stainless steels, as well as nickel alloys such as UNS N06059 and N06022, INCONEL alloy C-276, and INCONEL alloys 22, 625, and 686.

ERNiCrFe-7 is used for gas-tungsten-arc and gas-metal-arc welding of INCONEL 690.

ENiCrFe-3 electrodes are used for welding of nickel-chromium-iron alloys to themselves and for dissimilar welding between nickel-chromium-iron alloys and steels or stainless steels.

ERCuNi is used for gas metal and gas tungsten arc welding. Can also be used by oxy-fuel welding of 70/30, 80/20, and 90/10 copper nickel alloys. A barrier layer of nickel alloy 610 is recommended prior to overlaying steel with GMAW weld process.

ERNiCu-7 is a copper-nickel alloy base wire for GMAW and GTAW welding of Monel alloys 400 and 404. Also used for overlaying steel after first applying Layer of 610 nickel

ERNi-1 is used for GMAW, GTAW and ASAW welding of Nickel 200 and 201, joining these alloys to stainless and carbon steels, and other nickel and copper-nickel base metals. Also used for overlaying steel.

FAQ:

Q:How can I contact your company?
A:We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile

Q:Do you provide free samples?
A:Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.

Q:What is your payment terms?
A:T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal

Q:What is the lead time?
A:Usually sample lead time is 7 days after payment has been confirmed.

Q: What is ERNiCrMo-3 welding wire used for?
A: ERNiCrMo-3 is commonly used in chemical processing, power generation, marine, and aerospace industries.

Q: What materials can ERNiCrMo-3 weld?
A: It is ideal for welding a range of materials, including austenitic stainless steels, nickel alloys, and mild steel.

Q: What are the main advantages of ERNiCrMo-3?
A: Key benefits include excellent corrosion and oxidation resistance, high-temperature strength, good weldability, and the ability to weld dissimilar materials.
