Copper Welding Wire
Silver-Copper Phos Brazing Alloys BCup-4 BCup-5 BCup-8 Ncp25 Low Silver Brazing Alloys
Product Details
Silver-Copper-Phos brazing alloy can reduce themelting points,it can improve both the alloys' plasticity andwettability,as well as the alloys' strength and toughness.
Phos-Copper Silver Brazing Alloys are specialized filler materials used in brazing processes to join metals, particularly those involving copper and its alloys. These alloys combine silver, copper, and phosphorus to achieve enhanced flow characteristics, wetting properties, and joint strength. They are prized for their ability to create strong, reliable, and corrosion-resistant joints in various industrial applications.
Properties
Lower Melting Range: Phos-Copper Silver Brazing Alloys typically have a melting range between 780°C to 900°C (1436°F to 1652°F), depending on the specific composition. This relatively low melting range allows for joining without significantly affecting the base metals' properties.
Excellent Flow and Wetting: The presence of phosphorus enhances the alloy's ability to flow smoothly and wet the base metals, ensuring complete joint coverage and minimizing voids.
High Strength and Ductility: These alloys provide strong and ductile joints capable of withstanding mechanical stresses and thermal cycling.
Corrosion Resistance: The combination of silver and copper offers excellent resistance to corrosion and oxidation, making these alloys suitable for harsh environments.
Good Thermal and Electrical Conductivity: Ideal for applications requiring efficient heat dissipation or electrical conduction.
|
AWS Classification |
Applications |
|
ERNiCr-3 |
Used for welding 600, 601, and 800 alloys and dissimilar welding between stainless steel and carbon steel |
|
ERNiCrFe-7 |
Suitable for welding nickel-chromium-iron alloys under ASTM B163, B166, B167, and B168 standards |
|
ERNiCrFe-6 |
Designed for welding steel to nickel-chromium-iron alloys, as well as stainless steel to nickel-based alloys |
|
ERNiCrCoMo-1 |
Used for welding nickel-chromium-cobalt-molybdenum alloys and various high-temperature alloys |
|
ERNiCrMo-3 |
Suitable for nickel alloy, carbon steel, stainless steel, and low alloy steel welding, primarily used for 625, 601, 802 alloys, and 9% nickel alloys |
|
ERNi-CI |
Used for welding commercially pure nickel, malleable cast iron, and gray cast iron |
|
ERCuNi |
Suitable for welding 70/30, 80/20, and 90/10 copper-nickel alloys |
|
ERNiCu-7 |
Used for welding nickel-copper alloys such as B127, B163, B164, and B165 |
|
ERNi-1 |
Designed for welding pure nickel castings and forgings, including those under ASTM B160, B161, B162, and B163 standards |
|
ERNiFeMn-CI |
Suitable for welding nodular cast iron, ductile iron, malleable cast iron, and gray cast iron, as well as their dissimilar welding to stainless steel, carbon steel, low alloy steel, and various nickel alloys |
|
ERNiCrMo-4 |
Used for welding nickel-chromium-molybdenum alloys, or for welding nickel-chromium-molybdenum alloys to steel and other nickel-based alloys |
|
ERNiCrMo-11 |
uitable for self-welding nickel-chromium-molybdenum alloys, dissimilar welding with steel and other nickel alloys, and also for cladding applications |
|
ERNiCrMo-13 |
Used for welding low-carbon nickel-chromium-molybdenum alloys |
|
ENiCrMo-3 |
Designed for welding nickel-chromium-molybdenum alloys, including 625, 800, 801, 825, and 600 |
|
ENiCrFe-3 |
Used for welding nickel-chromium-iron alloys and for dissimilar welding with carbon steel |
|
ENiCrFe-2 |
Suitable for welding austenitic steel, ferritic steel, and high-nickel alloys, also used for 9% nickel alloy welding |
|
ENiCu-7 |
Primarily used for welding nickel-copper alloys and their dissimilar welding with steel |
|
ENiCrFe-7 |
Ideal for welding 690 (UNS N06690) nickel-chromium-iron alloys |
|
ENiCrMo-4 |
Designed for C-276 alloy welding and most nickel-based alloys |
|
ENiCrCoMo-1 |
Suitable for welding nickel-chromium-cobalt-molybdenum alloys and various high-temperature alloys |
|
ERCuNi |
Used for welding forged or cast 70/30, 80/20, and 90/10 copper-nickel alloys |
|
ENiCrMo-13 |
Used for welding low-carbon nickel-chromium-molybdenum alloys |
|
ENiCrMo-11 |
Used for welding low-carbon nickel-chromium-molybdenum alloys |
Physical & Mechanical Properties
|
Welding Wire Type |
Density (g/cm³) |
Melting Point (°C) |
Electrical Conductivity (% IACS) |
Coefficient of Thermal Expansion (10⁻⁶/°C) |
Tensile Strength (MPa) |
Yield Strength (MPa) |
Elongation at Break (%) |
|
Carbon Steel Welding Wire |
7.85 |
1450 |
8-10 |
11.8 |
400-550 |
300-400 |
20-25 |
|
Stainless Steel Welding Wire |
7.9 |
1350-1450 |
2-5 |
16-17 |
550-650 |
300-400 |
30-40 |
|
Aluminum Welding Wire |
2.7 |
600-660 |
>60 |
23.1 |
150-200 |
75-100 |
>20 |
|
Nickel Alloy Welding Wire |
8.4 |
1350-1400 |
1-2 |
13.1 |
600-800 |
400-600 |
30-40 |
|
Welding Rod Type |
Coating |
Electrical Resistivity (10⁻⁶ Ω·cm) |
Hardness (HV) |
Heat Resistance (°C) |
Tensile Strength (MPa) |
Yield Strength (MPa) |
Elongation at Break (%) |
|
Carbon Steel Welding Rod |
Acid coated, alkaline coated |
10-15 |
150-200 |
< 450 |
400-550 |
300-400 |
20-25 |
|
Stainless Steel Welding Rod |
Acid coated, alkaline coated |
60-80 |
200-400 |
< 800 |
550-750 |
350-450 |
25-35 |
|
Cast Iron Welding Rod |
Alkaline coated |
90-120 |
250-450 |
300-600 |
300-500 |
150-300 |
10-20 |
|
Nickel Alloy Welding Rod |
Alkaline coated |
80-100 |
200-300 |
< 1200 |
700-900 |
450-650 |
20-35 |
For more other size details, pls directly contact us
Phos-Copper Silver Brazing Alloys are versatile and find use in various industries, including:
Electrical and Electronics:Joining copper conductors, busbars, and heat sinks.Fabricating electrical components that require high conductivity.
HVAC (Heating, Ventilation, and Air Conditioning):Assembling copper tubing and fittings in refrigeration and air conditioning systems.
Automotive:Manufacturing and repairing cooling systems, radiators, and other copper-based components.
Plumbing:Creating leak-proof joints in copper piping for water supply and gas lines.
Aerospace:Producing lightweight and high-strength joints for various aerospace components.
Jewelry and Art Metalworking:Facilitating intricate and precise joins in decorative metal pieces.
